Double chamber medical infectious waste incinerator
Double chamber medical infectious waste incinerator
|
Incinerator Items/Model |
HICLOVER TS50(PLC) |
|
Picture |
|
|
Burn Rate (Average) |
30-50 kg/hour |
|
Feed Capacity(Average) |
20-50kg/feeding |
|
Control Mode |
PLC Automatic |
|
Intelligent Sensor |
Continuously Feeding with Worker Protection |
|
High Temperature Retention(HTR) |
Yes (Adjustable) |
|
Intelligent Save Fuel Function |
Yes |
|
Primary Combustion Chamber |
560Liters(0.56m3) |
|
Internal Dimensions |
100x80x70cm |
|
Secondary Chamber |
280L |
|
Smoke Filter Chamber |
Yes(dry) |
|
Feed Mode |
Manual |
|
Automatic False Alarm |
Yes |
|
Automatic Protection Operator(APO) |
Yes |
“Treatment of infectious waste, sharps, vials and small amounts of pathological waste.
The following average characteristics are considered*:
heating value above 2000 kcal/kg (8370 kJ/kg);
content of combustible matter above 60%;
content of non-combustible solids below 5%;
content of non-combustible fines below 20%;
moisture content below 30% by weight”
The medical waste incinerator shall be capable of reducing waste to ash not exceeding 10% in weight of the total combustible charges and below 1% in volume of the original waste.
“The medical waste incinerator will be installed outdoors. All incinerator components shall be suitable for but not limited to outdoor shaded installation, including electric motors, be resistant to corrosion, moisture and related weather elements.
Static stability of the incinerator must be achieved by a steel frame on which the incinerator doors, the burner and the protective shielding are mounted”
